Phanteks NV7 D-RGB Tempered Glass Case Black

PH-NV723TG_DBK01 | Phanteks
FREE METRO SHIPPING
FREE METRO SHIPPING
FREE METRO SHIPPING
FREE METRO SHIPPING
FREE METRO SHIPPING
FREE METRO SHIPPING
FREE METRO SHIPPING
$299
In stock
Order within 10h 0m 26s for same day dispatch!
Buy now, pay later!
On sale! (normally $349) The Phanteks NV7 D-RGB Tempered Glass Case features a tempered glass side and front panel, ultra-fine mesh panels for improved airflow and dust filtration, integrated fan/radiator brackets, LED cable covers, airflow covers, unique cable management tools, supports m-ITX, m-ATX, ATX, SSI-CEB and E-ATX motherboards, radiator support at the side, bottom, top (up to 360mm), and rear (up to 240mm) and supports a graphics card of up to 450mm in length.



Features


A True Showcase of Performance

The Phanteks NV7, with its unmistakable purpose design, highlights the system components with the motherboard at its centre. One of the main design elements of the NV7 is its strong and defining outer frame that captures and accentuates the hardware components. With a clean design from all sides, the NV7 allows you to place your system freely without the traditionally messy rear side. The glass panels offer a near-seamless view of the inside to further focus on the system components.

Phanteks NV7, Showcase Full-Tower Chassis, High Airflow Performance, Integrated D/A-RGB Lighting, Seamless Tempered Glass Design, 12 Fan Positions, Black

  • Create a picture-perfect PC with a seamless glass design.
  • Premium build quality throughout the strong and reinforced outer frame.
  • High Airflow Performance with fine mesh, dust filter and 12x 120mm fan positions.
  • Ready for ultimate water-cooling configurations with triple 360 radiator support.
  • Unique and super clean rear cable management for external cables with hinged door.
  • Integrated D-RGB lighting around the motherboard with built-in 2-channel D-RGB Controller that works out of the box.

Phanteks NV Series NV7 TG D-RGB Full Tower Case - Satin Black Feature 1

NV Series

The NV7 marks the beginning of a brand new series of Phanteks chassis. The NV Series envisions a chassis that supports the system components aesthetically and with cooling performance.

Phanteks NV Series NV7 TG D-RGB Full Tower Case - Satin Black Feature 2

A Picture Frame for Your System

Creating a picture-perfect build is the core element of the NV7, with fans positioned all around the motherboard, the heart of your system, like a picture frame. The near-seamless glass panels provide a perfect view of all your system components.

The unique layout of the NV7 puts the motherboard at the centre with fans all around.

  • Highlights the main system components at its centre
  • Strong and reinforced outer frame
  • Clean design from all sides for flexible placement

Phanteks NV Series NV7 TG D-RGB Full Tower Case - Satin Black Feature 3

Performance without Compromise

The ultra-fine performance mesh design is featured on all sides of the chassis, combining high airflow with good dust filtration. The bottom features a high-quality dust filter with an immense intake area that provides the best cooling performance to the GPU. A total of twelve 120 mm fan positions make sure the NV7 is ready for any challenge.

Unrestricted airflow guided directly to all system components.

  • Ultra-fine performance mesh everywhere
  • High quality dust filter and 65 mm bottom clearance for the best GPU cooling
  • Unique rear cable grid system for super clean external cable routing
  • Triple 360+240 radiators simultaneously

Phanteks NV Series NV7 TG D-RGB Full Tower Case - Satin Black Feature 4

Innovative Building Features

Integrated fan/radiator brackets, LED cable covers, airflow covers, and an array of unique cable management tools make any NV7 build stand out from the crowd.

The unique interior features improve both functionality and aesthetics.

  • Removable bottom and side fan/radiator brackets
  • Airflow covers prevent air circulation
  • Front-IO module can also be moved to the rear
  • Top and side LED cover along top edge of the motherboard
  • GPU Support Bracket firmly holds the GPU in place
  • Extensive cable management system behind the motherboard
  • Revamped 2-channel D-RGB controller that is plug-and-play

Specifications


General Data

Model Number PH-NV723TG_DBK01
Colour Satin Black

Case - Chassis

Case Dimension (D x W x H) 532 x 253 x 586 mm / 20.9 x 10.0 x 23.1 inch
Form Factor Full Tower
Materials Steel Chassis, Tempered Glass front and side panels
Motherboard Support ATX, micro-ATX, mini-ITX, SSI-CEB, E-ATX (up to 277 mm wide with LED Cover)
Front I/O 1 x USB 3.2 GEN 2 Type-C
2 x USB 3.0
D-RGB Mode button
D-RGB Colour button
D-RGB Speed button
D-RGB Channel button
Power button
Microphone / headphone Combo
Connectors Power SW (Power Switch)
Power LED
USB 3.0
USB 3.2 GEN 2 Type-E
HD-Audio
2 x D-RGB Channel A
2 x D-RGB Channel B
D-RGB Motherboard Input
2 x SATA Power
Window Yes, Front and Side Tempered Glass

Expansion & Drive Bays

PCI Slots (Expansion Slots) 8
Internal 3.5” Bay 2 (1 x if all SSD positions are used)
Internal 2.5” Bay 6 (4 x if both HDD positions are used)
Vertical GPU Support Yes, with optional bracket PH-VGPUKT4.0_03 or riser cable
D-RGB Controller Output 7 A per Channel, 4 A per port

Cooling - Fans

Side Fan 4 x 120 mm
Bottom Fan 3 x 120 mm / 3 x 140 mm
Top Fan 3 x 120 mm
Rear Fan 2 x 120 mm

Liquid Cooling - Radiators

Side Radiator Up to 360
Bottom Radiator Up to 360 / Up to 280
Top Radiator Up to 360
Rear Radiator Up to 240

Clearances

GPU Length 450 mm / 17.7 inch
CPU Cooler Height 185 mm / 7.3 inch
PSU Length 255 mm
Side 360 Radiator Maximum Size: 132 x 440 mm
Side 360 Radiator Thickness 65 mm (to GPU)
Top 360 Radiator Maximum Size: 132 x 440 mm
Rear 240 Radiator Maximum Size: 132 x 320 mm
Bottom Radiator Maximum Size: 140 x 440 mm

Support

Warranty 5 Years Limited
Scope of Delivery NV7 D-RGB Chassis
1 x SSD Storage / Cable bracket
1 x SSD Storage / HDD bracket
1 x Two-channel D-RGB Controller
1 x Front-IO Module
1 x Top LED Cover
1 x Side LED Cover
Accessory Bag / Box
1 x GPU Support bracket
2 x Airflow Covers
1 x D-RGB MB Adapter
6 x Zip ties
1 x Microfibre cloth
1 x Screw Assortment Box
34 x MB/SSD Screw
4 x Thumb Screw
9 x HDD Screw
1 x Standoff Removal Tool
1 x MB stand-off
4 x PSU Screw
1 x Extra R-Side Panel Screw
Backed by a 5-year Phanteks warranty.
